Išmanusis "BlueSmart" akumuliatoriaus įkroviklis 24V/8A, 1 išėjimas, IP22

A charger with unrivaled efficiency and low energy consumption with built-in Bluetooth technology. Sophisticated microprocessor controlled battery charger. One output, active cooling.

An extended warranty of 5 years applies to all models of chargers of the BlueSmart series.

Integrated bluetooth
You can set, display and configure the Blue Smart IP22 charger via your smartphone. You can view the charger and battery status. Even control the charger's functions with the VictronConnect app. The default value of voltage and current is displayed on the screen. You can download the app for iOS and Android here. You can also download the VictronConnect application for free from Google Play or the App Store.

High efficiency
With up to 94% efficiency, these chargers generate up to four times less heat compared to the industry standard. And once the battery is fully charged, power consumption drops to 0.5W, about five to ten times less than the industry standard.

Adaptive 6-stage charging algorithm: test - bulk - absorption - reconditioning - float - storage
The charger is equipped with a microprocessor controlled by "adaptive" Battery management. The adaptive function automatically optimizes the charging process

Storage mode: less maintenance and aging when the battery is not in use
Storage mode - if the battery has not been discharged for 24 hours. In storage mode, the voltage is reduced to 2.2V/cell (13.2V for a 12V battery) to minimize gassing and corrosion of the positive plate. Once a week the voltage is increased to the absorption level to "balance" the battery. This feature prevents electrolyte layering and sulfation.

Also charging Li-ion (LiFePO₄) batteries
LiFePO₄ batteries are charged in the bulk - absorption - float algorithm.

NIGHT and LOW settings
When the night or LOW mode is set, the output current is reduced to max. 25% of the rated power and the charger will be completely noiseless. NIGHT mode ends automatically after 8 hours. LOW mode can be ended manually.

Protection against overheating
The output current will decrease if the temperature rises above 50°C, but the charger will not be damaged.

Technical data:

Input voltage: 180 - 265 V alternating voltage (AC)
Frequency: 45 – 65 Hz
Charging current: 8 A
Charging current in night and LOW mode: 2 A
Power consumption without load: 0.5 W
Number of outputs (charged batteries): 1
Character of charging: adaptive four-stage
Absorption charging voltage: 28.8V
Trickle charge voltage: 27.6V
Storage Mode Voltage: 26.4V
Protections: output polarity reversal, output short circuit, overheating
Operating temperature range: from – 20 to + 50°C
Humidity: maximum 98%
Housing material: aluminum
Color: blue (RAL 5012)
Battery output: terminal block without cables
230 V AC input to charger: 1.5 m cable with classic plug
Degree of protection: IP 22
Plug type: CEE7/7 (Schuko)
Weight: 1.3 kg
Dimensions (height x width x length): 65 x 108 x 235 mm
